HPE Aruba AP-567EX — Directional Hazardous Location Wi-Fi 6 Outdoor AP Dubai with Installation
AED100 Login for member discount (10%)
- Hazardous Location certified: Class 1 Div 2 / ATEX Zone 2
- Dual-radio Wi-Fi 6 (2×2 MIMO per band)
- Directional antennas with 90° × 90° coverage
- Aggregate throughput up to ~1.49 Gbps
- Integrated Bluetooth 5 & Zigbee radios
- PoE+ powered, ≤15.6 W consumption
- Rugged IP66/67 enclosure for outdoor UAE/GCC climates
Out of stock
HPE Aruba AP-567EX — Directional Hazardous Location Wi-Fi 6 Outdoor Access Point
The HPE Aruba AP-567EX is a rugged, hazardous location certified outdoor access point built for explosive or high-risk environments in the UAE and GCC. With dual-radio Wi-Fi 6, integrated directional antennas, IoT radios, and a sealed enclosure rated for Class 1 Division 2 / ATEX Zone 2, the AP-567EX ensures safe and reliable connectivity for oil & gas, industrial plants, utilities, and outdoor sectors in Dubai, Sharjah, and across the region.
Key Features & Benefits
| Feature | Benefit |
|---|---|
| Hazardous Location certification (Class 1 Div 2 / ATEX Zone 2) | Safe operation in explosive or flammable environments |
| Dual 2×2 Wi-Fi 6 radios | High-efficiency performance with OFDMA, MU-MIMO, and low latency |
| Directional antennas (90° × 90° beamwidth) | Focused coverage for walkways, perimeters, and targeted outdoor areas |
| Throughput up to ~1.49 Gbps | Handles typical hazardous site traffic demands |
| Integrated Bluetooth 5 & Zigbee | Native IoT, location tracking, and sensor support |
| IP66/67 rugged enclosure with surge protection | Resistant to dust, moisture, salt, and extreme GCC climate |
| Advanced RF intelligence (ClientMatch, AirMatch, ACC) | Ensures reliable connections and interference mitigation |
Technical Specifications
- Certification: Hazardous Location (Class 1 Div 2, ATEX Zone 2)
- Radios: Dual 2×2 MIMO (5 GHz + 2.4 GHz), Wi-Fi 6 (802.11ax)
- Max data rate: ~1.49 Gbps aggregate (HE80 + HE20)
- Antenna gains: 6.8 dBi (5 GHz), 7.1 dBi (2.4 GHz), 3.0 dBi (BLE/Zigbee)
- Clients: up to 256 per radio; 16 BSSIDs per radio
- Power: PoE+ (802.3at), max ~15.6 W; idle 4.2 W; deep sleep 1.7 W
- Interface: 1 × Gigabit Ethernet RJ-45 (PoE-PD)
- Operating temperature: –40 °C to +55 °C (full solar load)
- Enclosure: IP66/67 weatherproof, salt spray & dust resistant
- RF & software: AirMatch, ClientMatch, ACC, Policy Enforcement Firewall, Dynamic Segmentation
- IoT radios: integrated Bluetooth 5 & 802.15.4 (Zigbee)
- Warranty: Limited lifetime hardware warranty
Why Choose It in Dubai & GCC
- Meets hazardous environment compliance for oil & gas, energy, and chemical industries in GCC
- Directional coverage reduces RF interference and focuses signal where needed
- Rugged enclosure withstands UAE climate — heat, dust storms, salt air, and humidity
- Integrated IoT radios enable smart monitoring without extra gateways
- Advanced RF controls help mitigate interference from nearby towers and metal infrastructure
- Easy to power via PoE+, simplifying hazardous site deployment
Netfix provides the **HPE Aruba AP-567EX** with full professional supply, installation, and hazardous-location certified deployment across Dubai and the wider GCC. Contact Netfix for a tailored installation quote in UAE.
